Head Support Hardware
Straight Style Hardware
- Simple, straight forward, robust, and economical support pad mounting.
- Easily achieved anterior, posterior, height, and rotational movements.
- The multi-axis supplies an extra rotational point on the vertical mounting rod.
- Both styles of mounting hardware come in 1 in. or 17mm versions to accommodate all mounting styles of our head support and positioning pads.
Link Style Hardware
- Multiple planes of adjustment allow critical adjustment of anterior, posterior, and angle.
- Separate links isolate adjustment planes and angles.
- Individual link adjustment achieves the most complex head support solutions.
- Standard removal option or integrated push button that allows the hardware to flip down, eliminating misplacement.
HMO500 Multi-Axis Hardware
- Lightweight Hardware.
- Easy to use and set up.
- Height Adjustable, Angle, Tilt and Swivel.
- Economical suppport pad mounting.
15mm Square Tubing
HMO476-1: Multi Axis Hardware with 15 mm Square Tubing, 1in. Mounting Ball
TWB486-1|TWB486-1FDM: 1in. Linking Hardware with 15mm Square Tubing
TWB486-1|TWB486-1FDM: Linking Hardware with 15mm Tubing, 1in. Ball
HMO476-17: Multi Axis Hardware with 15mm Square Tubing, 17mm Mounting Ball
TWB486-17MM|TWB486-17FDM: 17mm Linking Hardware with 15mm Square Tubing
TWB486-17MM|TWB486-17FDM: Linking Hardware with 15mm Square Tubing, 17mm ball
OBHSSMHMCB: Ottobock Head Support Mounting Hardware Multi-Axis Curved
: Ottobock mounting kit dimension diagram
OBHSSMHMSB: Ottobock Head Support Mounting Hardware Multi-Axis Straight
The tone deflector mechanically absorbs high tone rearward and angular forces, quick impact loading, and diverts and deflects angled loading 10° in all directions.
For 1 in. ball
TD101: Tone Deflector for 1" Ball
For 17mm Ball
TD100: Tone Deflector for 17mm Ball
SBM306: Seat Back Mount 15mm Square Tubing
Back mount replacement unit for 15mm (0.59in) square tubing.
FDM350: Headrest Flip Down Mount with Otto Bock & Millers Style Bolt Pattern
Provides flip down for mounting hardware with 1/2in (12.70mm) square tubing.
HMO-OB: Mounting Hardware Offset Bracket for Curved or Flat Back
Track that provides horizontal adjustment to the head support to adapt to asymmetry.
SBM300U: Universal Headrest Adapter Plate
Universal adapter that provides a larger range of accommodation for various backrests.
SBM351: Seat Back Mount Interface Clamp for 1" Tubing
Interface clamp allows mounting to be fastened onto a 1in (2.54cm) crossbar.
